FEATURES & TECHNOLOGY
EASY ASSEMBLY
ECO GARDEN House Dimensions
Height 88" x Width 72" x Depth 48"
Eco Garden House™
Smart Hub Electrical Control Panel
Built-in electrical panel houses the digital hub to control the Automatic Pump/Watering System, Lighting Control System and Thermal Temperature Control and Fan System. The entire Smart Hub Control Panel is easily programmed and conveniently accessed from the exterior of the Eco Garden House.
-
Automatic Pump/Water System Control
-
Automatic Lighting Control
-
Thermal Temperature Control
Eco Garden House™
Exhaust Fans and
Temperature Control System
The integrated programmable thermostatically controlled dual fan system allows for automatic exhaustion of the interior environment when reaching your desired preset temperature, allowing for maximum environmental control, yielding optimum growth of fruits, vegetables, herbs or flowers.
-
External ducting can be added on the outside of the unit (not included) through the external socks/access ports.
-
Additional Exhaust Fans can be added (2 included) to aid in temperature control.
-
A cooling system can be added (not included) to aid in temperature control.
Eco Garden House™
Fresh Water Pump System
Control the on/off and day/week timing of your integrated fresh water pump system with the programmable digital electrical hub
-
DO NOT RUN DRY
-
33 Gallon Tank Capacity
-
Always use a water soluble nutrient/fertilizer in the Eco Garden House in order to maintain a healthy watering system for your plants.
-
It is recommended that you regularly maintain your tanks with a water soluble cleaner.
-
-
Eco Garden House 8-Way Manifold Drip Irrigation Watering System output:
*Maximum open setting on pump and lines
*Pressure based on 1 ft. vertical head
Eco Garden House™
Gray Water Sump Pump System
Switch on the submersible sump pump to drain the gray water tank.
-
33 Gallon Tank Capacity
-
Always use a water soluble nutrient/fertilizer in the Eco Garden House in order to maintain a healthy watering system for your plants.
-
It is recommended that you regularly maintain your tanks with a water soluble cleaner.
-
-
3/4" Male Pipe Thread Fitting (MPT)
-
WARNING: Only Plug in when ready to drain! DO NOT RUN DRY!
-
Gray Water Sump Pump Drainage:
*Maximum open setting on pump and lines
*Pressure based on 1 ft. vertical head
Eco Garden House™
Drip Irrigation Watering System
Control the on/off and day/week timing of your drip irrigation system with the programmable digital electrical hub to manage the output of the fresh water pump system through the 8-Way integrated manifold with individual Flow Control adjustment for each port – Permitting precise flow adjustment for each outlet
Kit Includes:
-
8-Way Manifold
-
30’ Drip line with emitters
-
25’ Vinyl Supply Tubing
-
10 ea. ¼” Transfer Barb
-
10 ea. ¼” End Plug
-
10 ea. ¼” Tee Barb
-
10 ea. Galvanized Stakes
Eco Garden House™
Lighting System
Control the on/off and day/week timing of your eight tube high output reflective T5 overhead lighting system and your four vertical side lights with the programmable digital electrical hub.
8 Tube Overhead High Output Full Spectrum Adjustable Height T5 Grow Lights
4 Vertical High Output Full Spectrum T5 Grow Lights
-
The distance and intensity of light your plants can handle will vary by type of plant. To avoid damage from overexposure, we suggest you initially start your lighting system position greater than 24” away from the top of the plants and continue to lower your lighting system over a period of a few days until your grow lights are closer to the tops of your plants. Use this simple test to determine the final position of your grow lights: Place your hand just above the tops of your plants. Reposition the grow lights if you can feel the heat coming from the grow light system. Raise the light fixture until you can no longer feel the heat on your hand.
-
WARNING: Plants will discolor and damage from overexposure if the lighting source is too close.
-
Replace your Full Spectrum, High Output T5 Fluorescent Grow Light Bulbs when the ends darken. Note that once the ends have darkened, your T5 fluorescent grow bulbs may be producing as little as half of their light output.
-
Refer Eco Garden House General Lighting Guideline to determine the lighting schedule for your plants.
Eco Garden House™
Light Height Adjustment
Easy to access exterior crank handle allows you to quickly adjust the height of the overhead lighting system while maintaining a level plane for various stages of growth, maximizing plant yield.
-
The distance and intensity of light your plants can handle will vary by type of plant. To avoid burning, we suggest you initially start your lighting system position greater than 24” away from the top of the plants and continue to lower your lighting system over a period of a few days until your grow lights are closer to the tops of your plants. Use this simple test to determine the final position of your grow lights: Place your hand just above the tops of your plants. Reposition the grow lights if you can feel the heat coming from the grow light system. Raise the light fixture until you can no longer feel the heat on your hand
-
WARNING: Plants will discolor and damage from overexposure if the lighting source is too close.
Eco Garden House™
Mylar Shroud
The Eco Garden House’s 3-Piece canvas shroud is lined with a 95% reflective Mylar interior and zips together to encompass the entire unit. The shroud blocks out exterior light, allowing you complete control of your plant’s growing cycle. External viewing panels allow you to check on the progress of your plants without disturbing the growing cycle
Includes:
-
Front and rear zipper entry doors with tie backs
-
Windows with viewing access panels
-
Sock ducts for ventilation
-
Waterproof bottom tray to protect and guard against moisture
-
Exterior electrical access panels
Eco Garden House™
Tank Fill Indicator
Funnel shaped fill receptors on the fresh and gray water tanks allow you to easily replenish or purge the water supply. Water level indicator tells you when each tank is Full (horizontal indicator) or Empty (vertical indicator).
-
33 Gallon Tank Capacity
-
Always use a water soluble nutrient/fertilizer in the Eco Garden House in order to maintain a healthy watering system for your plants.
-
It is recommended that you regularly maintain your tanks with a water soluble cleaner.
-
-
3/4" or less hose for draining
